16 PON GPON OLT
Inclusive of all taxes
You Save: 0. Discount: 0%
-
Product is not available
Availability: In Stock
T G84/G.988 standard
Meet China's relevant GPON standards
►L3 OLT
Support static route RIP v1/v2、OSFP v2
►Easy to manage
Friendly EMS/Web/Telnet/CLI management
CLI command style similar to mainstream manufacturers
Support APP management
►Fully open platform
Open to any brand of ONT
►High performance cost
1U height compact design
Adopt mainstream chip scheme
SKU: V1600G2
Technical parameters
Item V1600G2
Chassis Rack 1U 19 inch standard box
1G/10G
Uplink Port
QTY 12
Copper 10/100/1000M auto-negotiation 8
SFP 1GE
4
SFP+ 10GE
GPON Port QTY 16
Physical Interface SFP Slot
Connector Type Class C+
Max splitting ratio 1:128
Management Ports 1*10/100BASE-T out-band port, 1*CONSOLE port
PON Port Specification(Class C+ module) Transmission Distance 20KM
GPON port speed Upstream 1.244G
Downstream 2.488G
Wavelength TX 1490nm, RX 1310nm
Connector SC/UPC
Fiber Type 9/125μm SMF
TX Power +3~+7dBm
Rx Sensitivity -30dBm
Saturation Optical
Power -12dBm
Dimension(L*W*H) 442*320*43.6mm
Weight 4.5kg
AC Power Supply AC:100～240V, 47/63Hz
DC Power Supply(DC:-48V) √
Double Power Module Hot Backup √
Power Consumption 85W
Operating Environment Working Temperature 0～+50℃
Storage Temperature -40～+85℃
Relative Humidity 5～90%(non-conditioning)
